Ranger
RCI-2970
Documentation Project
CBTricks.com
RCI-2950 VR (B) PCB (EPT295060Z)
Capacitors
|
Ref# |
Description |
MFR. Part No. |
|
C601 |
.001 OF 50WV Z SL, CERAMIC |
CCO501027L |
Potentiometers
|
Ref# |
Description |
MFR. Part No. |
|
RF/CAL |
VR 1KB-20KB |
RV10203456 |
Connectors
|
Ref# |
Description |
MFR. Part No. |
|
J601 |
PCB CONN. SOCKET 3P |
EX07N41216 |
|
J602 |
PCB CONN. SOCKET 3P |
EX07N41216 |
